Indeng Monofl – VRD Centrifugal Pumps

• Casing: Volute type of robust construction to give high efficiency. A deep stuffing box is incorporated and internally sealed to prevent the ingress of air using gland packing as standard. The option of different types of hard faced mechanical seals may be fitted. The delivery branch can be rotated to give any one of eight different positions to enable the most suitable pipework layout to be used.
• Impeller: Double shrouded and secured to the shaft by locknut and key. On the large pump sizes, balancing holes are utilized to minimise hydraulic thrust.
• Shaft: Accurately machined from high quality stainless steel and designed to withstand the most severe duties without vibration. A renewable shaft sleeve is provided as standard on all larger pumps.

NOTE: Product information should be used as a guide only and should not be used for pump selection. For further information, please contact Malcolm Thompson Pumps on 1800 439 607.
