For pumping and conveying large quantities of heavy flammable liquids out of containers, tanks and open containers. The pump can be used horizontally, mounted onto a base plate or fixed vertically.
F 640 TR
For horizontal use
- Can be used horizontally or vertically
- Pumps fluids containing solids
- Motor can be changed
- Pump is hermetically sealed
- Comes with console for dry installation
Industries Served
• Anodizing solution
• Vegetable fibre suspension
• Water-based lacquers
• Alkaline pickling vats
• Industrial effluent
• Flow rate: max. 733 l/min1
• Delivery head: max. 33 mwc1
• Viscosity: min. 1 mPas – max. 2000 mPas1
• Diameter pump housing: max. 230 mm2
• Diameter mounting flanges: max. 185 mm2
• Materials outer tube: Polypropylene
• Media / Fluids: Acids, AdBlue®, Alkalis, Fuels
• Seal: mechanical seal
• Container: Tanks > 1000 liters
Please contact one of our expert advisors or contact person in the office for an optimal motor dimensioning.
